    Three Phase Transmission Line Testing System

    Nvis 8023

    Product Description

    Three Phase Transmission Line Testing System is a key learning concept for Electrical Engineers. Transmission Line Training System is exclusively designed to deliver the learning aspects of the electrical transmission line. Digital display is provided for easy measurement of voltage, current, power, power factor, etc. These parameters help students to learn the characteristics of transmission line and calculations of the ABCD, H, Z parameters, voltage regulation of three phase transmission line, fault analysis and protection, Ferranti effect, etc.

    Transmission Line Training System is an ideal platform to enhance education, training, skills & development. It enables demonstrate and test the characteristics and management of high voltage distribution networks, with small scale components.

    Product Features

    • Number of Pi Sections: 10 nos.
    • Operating Voltage: 3-Phase, 415V, 50Hz Supply.
    • Current Rating: 10 Amp.
    • Line simulation through air cored inductor (DCC).
    • Each Pi-section for every 40Km.
    • 3-phase auto transformer 20Amp – 1no.
